Gabriel Tube Fittings, a top-notch manufacturer and supplier located in Cairo, Egypt, proudly offers high-quality **Titanium BSP / NPT Fittings** designed for high-performance and corrosion-sensitive applications. Built to withstand tough conditions, these fittings ensure dependable and leak-proof threaded connections for fluid and gas handling systems. Crafted to meet international standards, Gabriel’s BSP (British Standard Pipe) and NPT (National Pipe Taper) titanium fittings boast impressive strength-to-weight ratios, outstanding corrosion resistance, and long-lasting reliability, making them the go-to choice in industries that demand durable, non-reactive components.
Typically, Gabriel’s Titanium BSP and NPT fittings are constructed from **Titanium Grade 2** or **Grade 5** alloys. Grade 2 is a commercially pure titanium known for its excellent corrosion resistance and moderate strength, while Grade 5 (Ti-6Al-4V) provides enhanced strength and durability. These fittings are lightweight, non-magnetic, and resistant to a broad spectrum of aggressive chemicals, including seawater, chlorides, and acids. The precision-machined BSP and NPT threads guarantee tight, secure seals in pressurized systems. Additionally, these titanium fittings are thermally stable and suitable for both high and low-temperature service environments.
| Grade | Ti | C | O | H | N | Fe | Al | V |
| BSP Ti Grade5 | 90 min | – | 0.2 max | – | – | 0.25 max | 6 min | 4 min |
| NPT Ti Grade2 | 99.2 min | 0.1 max | 0.25 max | 0.015 max | 0.03 max | 0.3 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium BSP Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
| Titanium NPT Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| TI GRADE | UNS | WNR. |
| GR 2 | R50400 | 3.7035 |
| GR 5 | R56400 | 3.7165 |
Contact us to get a quick quote for your requirement.
Titanium BSP / NPT fittings find extensive use in chemical processing, offshore and marine systems, aerospace, desalination plants, and the pharmaceutical industry. Their corrosion resistance, ability to handle high pressure, and lightweight nature make them perfect for connecting tubing and piping in instrumentation lines, hydraulic systems, and high-purity fluid transport. Common applications include chemical feed lines, seawater cooling systems, and equipment used in reactors or laboratories.
Titanium BSP/NPT fittings are widely used in applications requiring high strength and corrosion resistance. In the aerospace industry, they are essential for hydraulic systems, fuel lines and engine components due to their light weight and durability. In marine and offshore applications, they withstand strong salt water, making them ideal for pipelines and conveyors. It is used by the oil and gas industry in high-pressure reactors. In addition, manufacturing facilities rely on titanium inserts to contain aggressive chemicals and ensure long-term leak-free performance in critical systems.
Please feel free to contact us if you need any further information or for enquiry.
