Union Cross

Home > Union Cross

Based in Cairo, Egypt, Gabriel Tube Fittings has earned a solid reputation as a reliable manufacturer and supplier of top-notch industrial piping components, including union crosses. With a focus on precision engineering and the use of durable materials, they create union crosses that ensure secure, leak-proof four-way pipe connections. These fittings are designed for easy installation and maintenance, allowing for quick disassembly and reassembly without the need to cut pipes. Gabriel Tube Fittings is dedicated to providing dependable solutions, ensuring that all their products adhere to strict quality standards, and they cater to a diverse range of industries both locally and globally with efficient, long-lasting piping components.

Union Cross Hydraulic Tube Fittings Supplier in Cairo, Union Cross Compression Fittings Supplier Price List in Alexandria, Ermeto Fittings Manufacturer in Giza, Niobium Hydraulic Fittings In Port Said, Single Ferrule Fittings, Din 2353 Union Cross Hydraulic Fittings Exporter in Alexandria, Union Cross Hydraulic Pipe Fittings Manufacturer in Cairo, Bite Type Union Cross Hydraulic Fittings in Cairo, Egypt.

Union crosses are generally crafted from corrosion-resistant materials like stainless steel, brass, or carbon steel, chosen for their impressive mechanical strength and durability. These fittings boast excellent tensile strength, along with resistance to high pressures and temperatures, and they are built to withstand corrosion. The design features a cross-shaped connection with union joints, allowing for four-way pipe branching that can be easily connected or disconnected for maintenance or system expansion, all while ensuring a tight, leak-proof seal for optimal performance.

Union Cross Specifications

UNION TEE
TUBE OD		THREAD UN / UNF	S	L	D	PART NO.
mm	inch	N	mm	mm	mm	PART NO.
6	1/4	7/16-20	11	22.6	4.4	4F-T
8	5/16	1/2-20	13	24.1	6	5F-T
10	3/8	9/16-18	14	26.9	7.5	6F-T
12	1/2	3/4-16	19	31.8	9.9	8F-T
14/15/16	5/8	7/8-14	22	36.8	12.3	10F-T
18/20	3/4	11/16-12	27	42.2	15.5	12F-T
25	1	1 5/16-12	33	46	21.5	16F-T
28/30/32	1 1/4	15/8-12	41	52.3	27.5	20F-T
35/38	1 1/2	1 7/8-12	48	59.2	33	24F-T

Top Union Cross Manufacturing Company in Cairo

At Gabriel Tube Fittings, we are the leading supplier, manufacturer, and exporter of Union Cross in Cairo, Egypt. Our state-of-the-art manufacturing facilities, strategically located in the Egypt, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.

Types of Union Cross

Union Cross Hydraulic Bulkhead Union, Alloy Tube To Union, 24 Degree Cone Fittings Price in Cairo, Union Cross Hydraulic Male Branch Tee Union Cross Hydraulic Supplier in Alexandria, Niobium Hydraulic Fittings Manufacturer in Giza, Flareless Fittings Price in Port Said, Parker Union Cross Hydraulic Fittings Supplier and Manufacturer in Cairo, Union Cross Hydraulic Male Elbow In Cairo, Egypt.

Largest Manufacturer and Supplier of Union Cross in Cairo, Egypt

You’ll find union crosses commonly used in sectors such as chemical processing, oil and gas, water treatment, and HVAC systems, where multiple pipeline branches are essential. They simplify complex piping networks by providing reliable four-way connections that make installation, repair, and modification straightforward, minimizing downtime. With their ease of maintenance and robust construction, union crosses are vital in systems that require both flexibility and durability to ensure efficient and safe operation.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Union Cross Uses

Union Cross fittings are widely used in fluid and gas control systems, allowing the connection of four pipes or tubes in a cross configuration. These fittings are ideal for applications that require efficient distribution of fluids or gases in multiple directions, such as hydraulic systems, pneumatic systems, chemical processing, and oil and gas industries. They are crucial in systems where space optimization and high-pressure capabilities are essential, ensuring reliable performance in complex pipelines while maintaining flow integrity and preventing leaks in critical operations.
