Home > Alloy 20 Ball Valve
Gabriel Tube Fittings, based in Cairo, Egypt, stands out as a top manufacturer and supplier of Alloy 20 Ball Valves, celebrated for their exceptional corrosion resistance, strength, and reliability. These valves are expertly designed for seamless on-off fluid control, excelling in tough, corrosive industrial settings. At Gabriel Tube Fittings, they leverage cutting-edge manufacturing technology, precise engineering, and rigorous quality checks to guarantee long-lasting performance and leak-proof operation. Their Alloy 20 Ball Valves comply with international standards and are widely trusted across various sectors, including chemical processing, pharmaceuticals, food and beverage, and marine applications, where durability and safety are paramount.
Constructed from a nickel-iron-chromium alloy with added molybdenum and copper, Alloy 20 Ball Valves boast remarkable resistance to sulfuric acid, chlorides, and other harsh chemicals. This alloy provides a tensile strength of around 550 MPa, along with high ductility and excellent resistance to pitting, crevice corrosion, and stress corrosion cracking. These valves maintain their mechanical integrity even under high pressure and temperature, making them perfect for handling corrosive and high-purity media.
| STANDARD | API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
| Grade | % | Ni | Cr | Mo | Cu | Nb | C | Mn | Si | P | S |
Alloy 20 | Min. | 32 | 19 | 2 | 3 | 0.1 | 1 | ||||
| Max. | 38 | 21 | 3 | 4 | 0.3 | 0.02 | 2 | 0.7 | 0.02 | 0.005 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi – 80000 , MPa – 551 | Psi – 35000 , MPa – 241 | 30 % |
At Gabriel Tube Fittings, we are a leading supplier, manufacturer, and exporter of Alloy 20 Ball Valve in Cairo, Egypt. Our state-of-the-art manufacturing facilities, strategically located in the Egypt, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.
Alloy 20 Ball Valves find extensive use in the chemical and petrochemical industries, pharmaceutical production facilities, marine systems, and food processing plants. Their corrosion resistance and smooth functionality make them ideal for managing the flow of acids, alkaline solutions, and other reactive fluids. These valves promise safe, efficient, and maintenance-free operation, minimizing downtime and prolonging the lifespan of process systems in demanding industrial environments.
Contact us to get a quick quote for your requirement.
Alloy 20 ball valves are widely used in industries that handle highly corrosive substances. They are commonly found in chemical processing plants, particularly for handling sulfuric acid, phosphoric acid, and other harsh chemicals. These valves are also used in petrochemical, pharmaceutical, and food processing industries due to their resistance to corrosion and contamination. Additionally, they are ideal for environments with high chloride levels, such as seawater and brine processing, and are utilized in waste treatment facilities where corrosion resistance and durability are critical.
Please feel free to contact us if you need any further information or for enquiry.
