Gabriel Tube Fittings, located in Cairo, Egypt, has built a solid reputation as a reliable manufacturer and supplier of top-notch industrial components, including tantalum ball valves. These valves are celebrated for their outstanding corrosion resistance and dependability, making them perfect for even the most challenging chemical and high-purity environments. Each valve is crafted to meet the highest international standards, guaranteeing excellent sealing, durability, and operational efficiency. Whether serving local or international markets, Gabriel Tube Fittings provides long-lasting, high-performance valve solutions tailored to the rigorous demands of chemical processing, pharmaceuticals, and high-tech applications.
Tantalum ball valves are constructed from high-purity tantalum metal or tantalum-lined steel, selected for their remarkable ability to resist corrosion from strong acids like hydrochloric, sulfuric, and nitric acids. These valves boast impressive mechanical strength, a high melting point, and resistance to oxidation, even under high temperatures. The precisely engineered ball mechanism allows for smooth, quarter-turn operation with a secure shut-off. Thanks to tantalum’s exceptional chemical inertness, these valves ensure reliable performance and a long service life in highly corrosive and reactive settings.
| STANDARD | API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
|
Element |
R05200 (%,Max) |
R05400 (%,Max) |
R05252 (Ta-2.5W) (%,Max) |
R05255 (Ta-10W) (%,Max) |
|
C |
0.01 |
0.01 |
0.01 |
0.01 |
|
O |
0.015 |
0.03 |
0.015 |
0.015 |
|
N |
0.01 |
0.01 |
0.01 |
0.01 |
|
H |
0.0015 |
0.0015 |
0.0015 |
0.0015 |
|
Fe |
0.01 |
0.01 |
0.01 |
0.01 |
|
Mo |
0.02 |
0.02 |
0.02 |
0.02 |
|
Nb |
0.1 |
0.1 |
0.5 |
0.1 |
|
Ni |
0.01 |
0.01 |
0.01 |
0.01 |
|
Si |
0.005 |
0.005 |
0.005 |
0.005 |
|
Ti |
0.01 |
0.01 |
0.01 |
0.01 |
|
W |
0.05 |
0.05 |
2.0-3.5 |
9.0-11.0 |
|
Ta |
Remainder |
Remainder |
Remainder |
Remainder |
| Properties | Metric | Imperial |
| Density | 16.65 g/cm3 | 0.6015 lb/in3 |
| Melting point | 2850 °C | 5162°F |
| Boiling point | 6000 °C | 10832°F |
At Gabriel Tube Fittings, we are a leading supplier, manufacturer, and exporter of Tantalum Ball Valve in Cairo, Egypt. Our state-of-the-art manufacturing facilities, strategically located in the Egypt, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.
You’ll find tantalum ball valves widely utilized in chemical processing, semiconductor manufacturing, pharmaceutical production, and laboratory systems where corrosion resistance and purity are paramount. They excel at controlling the flow of highly corrosive or ultra-pure fluids without the risk of contamination or degradation. With their sturdy construction, precise control, and minimal maintenance needs, they are an outstanding choice for applications involving acids, chlorides, and other reactive chemicals. Tantalum ball valves from Gabriel Tube Fittings promise safe, efficient, and durable operation in even the toughest industrial environments.
Contact us to get a quick quote for your requirement.
Tantalum ball valves are widely used in various industries due to their exceptional corrosion resistance and durability. They are commonly employed in chemical processing plants for handling aggressive acids and alkalis, ensuring safe and efficient flow control. In the pharmaceutical industry, tantalum valves facilitate the handling of sensitive materials without contamination. Additionally, they find applications in the aerospace sector for high-performance systems requiring reliable sealing under extreme conditions. Their ability to withstand harsh environments makes tantalum ball valves essential for maintaining safety and efficiency in demanding applications.
