Monel Condensate Pots

Home > Monel >Monel Condensate Pots

Gabriel Tube Fittings is a premier manufacturer and distributor specializing in high-quality Monel condensate pots. Renowned for their exceptional durability and corrosion resistance, our Monel condensate pots are designed to efficiently collect and separate condensate in various industrial applications. With a commitment to excellence and innovation, we provide products that meet the stringent demands of industries such as chemical processing, power generation, and marine operations. Our extensive expertise and customer-focused approach ensure that we deliver reliable solutions tailored to meet your specific needs, solidifying our position as a trusted partner in the field of tube fittings and condensate management.

Monel Type A Condensate Pot with Galvanized Plating Manufacturer Cairo, Monel® Alloy Type B Condensate Pot with Zinc Plating Dealer Alexandria, Monel Type C Condensate Pots with 4 Ports Dealers Giza, Monel Type A Condensate Pots with 2 Ports Exporter In Port Said, UNS N04400 Type B Condensate Pots Exporter In Cairo, Monel Type C Condensate Pot with Zinc Plating Exporter In Cairo, Egypt.

**Gabriel Tube Fittings**, located in Cairo, Egypt, is dedicated to crafting and supplying top-notch **Monel Condensate Pots** that shield pressure instruments from the harmful effects of condensate and moisture found in steam and gas lines. These condensate pots serve as a protective barrier, effectively preventing liquid carryover and ensuring that pressure measurements remain accurate and reliable, even in tough industrial settings.

Monel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Chemical Compositions Of Monel Alloy Condensing Pot

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel Alloy Condensing Pot	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min

Sizing Of Monel Alloy Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Top Monel Condensate Pots Manufacturing Company in Cairo

Made from **Monel 400**, a nickel-copper alloy celebrated for its outstanding resistance to corrosion from seawater, acids, and alkalis, Gabriel’s condensate pots promise exceptional durability and a long lifespan in challenging chemical and marine environments. Their sturdy construction and precise machining make these pots perfect for use in offshore platforms, petrochemical plants, power generation facilities, and chemical processing operations.

Types of Monel Condensate Pots

Monel Condensate Pot Type A Price in Cairo, Monel Type B Condensate Pot with Red Oxide Coated Manufacturer Supplier in Alexandria, Monel Condensate Pot Type C Manufacturer in Giza, Monel® Alloy Type A Condensate Pot with Red Oxide Coated Price in Port Said, K500 Monel Condensate Pots Type B Manufacturer in Cairo, 400 Monel Type C Condensate Pot Dealer In Cairo, Egypt.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Monel Condensate Pots Supplier in Cairo, Egypt

**Monel Condensate Pots** come in a variety of sizes and connection types, including threaded and flanged ends, allowing for seamless integration into existing instrumentation and piping systems. They efficiently separate condensate from gas or steam lines, safeguarding sensitive gauges, transmitters, and switches from moisture and corrosion damage. With Gabriel’s condensate pots, you can expect enhanced system reliability, lower maintenance needs, and improved safety in critical process applications.

Monel Condensate Pots Uses

Monel condensate pots are widely used in various industrial applications due to their exceptional corrosion resistance and durability. They are commonly utilized in steam systems to collect and separate condensate, preventing water hammer and improving system efficiency. In the chemical processing industry, they serve as reliable vessels for handling corrosive fluids. Additionally, Monel condensate pots are ideal for marine applications, where exposure to saltwater and harsh conditions is prevalent. Their robust design also makes them suitable for power generation, ensuring optimal performance and longevity in demanding environments.
