Gabriel Tube Fittings, based in Cairo, Egypt, is a reputable manufacturer and supplier of top-notch **Stainless Steel Tube Fittings** that are built for durability and leak-proof performance in essential fluid and gas handling systems. These fittings are engineered for a variety of industries, including oil & gas, chemical processing, power generation, pharmaceuticals, and food & beverage. They deliver precision, strength, and impressive corrosion resistance. Gabriel’s fittings are crafted to meet international standards for performance and reliability, ensuring secure connections in both high- and low-pressure systems across various operating environments.
Typically, Stainless Steel Tube Fittings are made from **grades like SS 304, SS 316, and SS 316L**, which are celebrated for their outstanding corrosion resistance, mechanical strength, and smooth surface finish. SS 316 and 316L, in particular, excel in resisting chlorides and acidic environments, making them ideal for harsh conditions. These fittings boast high tensile strength (up to 600 MPa), are non-magnetic, and provide excellent weldability and formability. With precision threads and ferrule systems, they ensure tight, vibration-resistant seals in high-pressure systems, preventing any leakage or loss of integrity.
| Specifications | ASTM A182, A276, A479 / ASME SA182, SA276, SA479 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Equivalent To | SWAGELOK, PARKER, DK-LOK, HOKE |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application | |
| Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | C | Mn | Si | P | S | Cr | Ni |
| Stainless Steel Tube Fittings | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | 8 – 11 |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Stainless Steel Tube Fittings | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
At Gabriel Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel Tube Fittings in Cairo, Egypt. Our advanced manufacturing facilities, strategically located in the Egypt, allow us to provide high-quality solutions tailored to your specific requirements. With a substantial inventory of over 16,000 tons of top-grade stainless steel materials, we are well-equipped to meet your needs promptly. Our commitment to excellence and efficiency ensures that we consistently maintain available stock to support your demands.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Stainless Steel Tube Fittings | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
Stainless Steel Tube Fittings find their place in instrumentation, hydraulic, and process control systems, connecting tubing securely and reliably. Their applications range from offshore platforms and chemical injection systems to refineries, water treatment plants, biopharmaceutical facilities, and laboratory settings. Their ability to endure high temperatures, corrosion, and mechanical stress makes them perfect for critical applications that demand longevity and safety. With Gabriel’s stainless steel fittings, you can expect reduced maintenance and easy installation.
Contact us to get a quick quote for your requirement.
Stainless Steel Tube Fittings are widely utilized across various industries due to their superior corrosion resistance and durability. In the chemical processing industry, they facilitate the safe transport of corrosive substances, while in the oil and gas sector, they are essential for connecting pipes in high-pressure environments. Additionally, these fittings are employed in the food and beverage industry, ensuring hygiene and safety during the processing and transportation of products. Their reliability also makes them suitable for marine applications, automotive systems, and construction, providing long-lasting performance in demanding conditions.
Please feel free to contact us if you need any further information or for enquiry.
