5 Way Ball Valve

Home > 5 Way Ball Valve

Gabriel Tube Fittings, located in Cairo, Egypt, has earned a solid reputation as a reliable manufacturer and supplier of top-notch industrial components, including their impressive 5-way ball valves. Renowned for their precision engineering, durability, and dependable performance, these valves are expertly designed to handle intricate fluid flow paths in advanced piping systems. Built to comply with strict international standards, Gabriel’s 5-way ball valves ensure leak-proof operation, smooth control, and a long lifespan. Catering to a diverse array of industries both locally and globally, Gabriel Tube Fittings provides efficient and robust valve solutions tailored for demanding industrial applications.

5 Way Ball Valve Supplier In Giza, 5 Way Screwed End Ball Valve Exporter In Cairo, 5 Way Threaded Ball Valve Dealer In Alexandria, 5 Way Butt Weld Ball Valve Supplier in Cairo, 5 Way Socket Weld Ball Valve Price List in Alexandria, ANSI B 16.5 Ball Valve Manufacturer in Giza, ASTM A 216 GR. WCB Ball Valve in Port Said, ASTM A351 Gr. CD4Mcu Ball Valve Exporter in Alexandria, ASTM A 351 GR. CN7M Ball Valve Manufacturer in Cairo, 4 Way Ball Valve In Cairo, Egypt.

These 5-way ball valves are typically made from tough materials like stainless steel, brass, or carbon steel, chosen for their outstanding corrosion resistance and mechanical strength. With five ports and various flow configurations, these valves allow for complex flow control, including mixing, diverting, and sequential operations—all within a single compact unit. Their mechanical features boast high tensile strength, low torque operation, and excellent sealing performance, guaranteeing reliable and precise flow regulation even under high pressure and temperature.

Specification of 5 Way Ball Valve

Design Standard	BS EN ISO 17292 (BS 5351) / BS EN ISO 12516 / BS EN 1983 / ASME B 16.34 / API 6D
Inspection & Testing Standard	BS EN ISO 12266 – I (BS 6755 – I)
Flange To Flange Distance	Mfg. Standard
End Connection	Flanged End to ANSI B 16.5, Class 150 / 300
	BS 10 Table D / E / F / H
	PN 6 / PN 10 / PN 16 / PN 25 / PN 40
	DIN Standard / JIS Standard / IS Standard
Manufacturing Size Range	1/2″ (DN15) to 6″(DN 150)
Pressure Rating of Valve	150# / 300#
	PN 10 / PN 16 / PN 25 / PN 40
Valve Operation	Manual Hand Lever / Worm-Gear Actuator Operated
	Pneumatic Rotary Quarter Turn Actuator / Electrical Actuator

5 Way Ball Valve Supplier In Giza, 5 Way Screwed End Ball Valve Exporter In Cairo, 5 Way Threaded Ball Valve Dealer In Alexandria, 5 Way Butt Weld Ball Valve Supplier in Cairo, 5 Way Socket Weld Ball Valve Price List in Alexandria, ANSI B 16.5 Ball Valve Manufacturer in Giza, ASTM A 216 GR. WCB Ball Valve in Port Said, ASTM A351 Gr. CD4Mcu Ball Valve Exporter in Alexandria, ASTM A 351 GR. CN7M Ball Valve Manufacturer in Cairo, ANSI B 16.5 Ball Valve In Cairo, Egypt.

Top 5 Way Ball Valve Manufacturing Company in Cairo

At Gabriel Tube Fittings, we are the largest supplier, manufacturer, and exporter of 5 Way Ball Valve in Cairo, Egypt. Our advanced manufacturing facilities, strategically positioned in the Egypt, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands

Materials List for 5 Way Ball Valve

Item	Part Name	Material	Qty
1	Body	A351 Gr. CF8M	1
2	End Cap	A351 Gr. CF8M	3
3	Blind End Cap	A351 Gr. CF8M	1
4	Ball	316SS	1
5	Stem	316SS	1
6	Seat	RTFE ( 15% C.F.)	4
7	Body Seal	PTFE	4
8	Body Bolt	304SS	16
9	Body Bolt Washer	304SS	16
10	Thrust Washer	PEEK	1
11	Stem O-Ring	Viton 90	1
12	Stem Packing Set	TFM	1
13	Packing Gland	304SS	1
14	Belleville Washer	301SS	4
15	Gland Nut	304SS	1
16	Gland Nut Lock Washer	304SS	1
17	Stop Pin	304SS	1
18	Stop Plate	304SS	1
19	Handle	304SS	1
20	Handle Nut	304SS	1
21	Handle Cover	Vinyl	1
22	Trunnion Bearing	PEEK	1
23	Trunnion Bolt	304SS	3
24	Trunnion	316SS	1
25	Trunnion Gasket	PTFE	1
26	Stem Set Pin	316SS	1

Types of 4 Way Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

5 Way Ball Valve Supplier in Cairo, Egypt

Commonly found in sectors such as chemical processing, oil and gas, pharmaceuticals, and HVAC systems, 5-way ball valves are perfect for applications that require versatile flow paths and efficient system control without the hassle of multiple valves. Their sturdy design and adaptability simplify installation and maintenance, ensuring safe, reliable, and efficient operation across various industrial settings. Gabriel’s 5-way ball valves are your go-to solution for optimal performance in critical flow management tasks.

5 Way Ball Valve Uses

A 5-way ball valve is widely used in various industries due to its versatile flow control capabilities. Common applications include chemical processing, where it directs the flow of corrosive substances, and HVAC systems for regulating heating and cooling fluids. In oil and gas, it facilitates multi-directional flow management and isolation of pipelines. Additionally, it is used in water treatment facilities for effective flow distribution and in manufacturing processes requiring precise fluid control. Its ability to connect multiple lines enhances efficiency and reduces system complexity in these applications.
