Gabriel Tube Fittings, located in Cairo, Egypt, stands out as a top manufacturer and supplier of Hydraulic Bulkhead Unions. These fittings are celebrated for their precision engineering, durability, and leak-proof performance. They’re specifically designed to create secure connections through panels or enclosures, ensuring efficient fluid transfer in high-pressure hydraulic systems. Gabriel Tube Fittings employs cutting-edge production technology and strict quality control measures to meet international performance and reliability standards. Their Hydraulic Bulkhead Unions are trusted by various industries, including oil and gas, marine, power generation, and heavy machinery, thanks to their sturdy construction and long-lasting service life.
Typically, Hydraulic Bulkhead Unions are crafted from high-strength materials like stainless steel, carbon steel, or brass, allowing them to endure high pressure and vibration. These fittings boast impressive mechanical properties, with tensile strength surpassing 500 MPa and exceptional corrosion resistance. The design incorporates a double ferrule or compression-type connection, guaranteeing a tight, leak-free seal. They can handle a broad spectrum of hydraulic fluids and maintain their structural integrity even in extreme operating conditions.
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | |
| MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 | |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| BODY TYPE | BAR STOCK |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| STEEL – ASTM 108/A105, JIS G4051 S20C, S45C,/G3201 SF440A. | |
| BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
At Gabriel Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Bulkhead Union in Cairo, Egypt. Our advanced manufacturing facilities, strategically positioned in the Egypt, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| Body Material | Size 1 | Size 2 |
|---|---|---|
| Alloy 400 | 1/16″ | 1/16″ |
| Alloy C-276 | 1/8″ | 1/8″ |
| Brass | 3/16″ | 3/16″ |
| Stainless Steel 316 | 1/4″ | 1/4″ |
| 5/16″ | 5/16″ | |
| 3/8″ | 3/8″ | |
| 1/2″ | 1/2″ | |
| 5/8″ | 5/8″ | |
| 3/4″ | 3/4″ | |
| 1″ | 1″ | |
| 1-1/4″ | 1-1/4″ | |
| 1-1/2″ | 1-1/2″ | |
| 2″ | 2″ | |
| 3mm | 3mm | |
| 4mm | 4mm | |
| 6mm | 6mm | |
| 8mm | 8mm | |
| 10mm | 10mm | |
| 12mm | 12mm | |
| 14mm | 14mm | |
| 15mm | 15mm | |
| 16mm | 16mm | |
| 18mm | 18mm | |
| 20mm | 20mm | |
| 25mm | 25mm | |
| 38mm | 38mm |
Contact us to get a quick quote for your requirement.
You’ll find Hydraulic Bulkhead Unions commonly used in hydraulic and pneumatic systems, process control lines, and instrumentation setups. They’re perfect for connecting tubing through walls, bulkheads, or panels while preserving the system’s integrity. These fittings are crucial in applications that demand secure and reliable connections in tight or high-vibration environments. With their straightforward installation, leak-proof design, and resistance to corrosion, they’re a trustworthy choice for efficient hydraulic and fluid control operations.
Hydraulic bulkhead union are used to create safe, leak-proof connections between hydraulic lines through walls, panels, or bulkheads. They are essential in applications where hydraulic systems must be transported within system constraints, such as aircraft, ships, and industrial equipment This association ensures pressure-free connections in confined and frequently used areas aerospace, marine, oil and gas industries, and construction High pressure, extreme temperatures , and vibration resistance make it ideal for use in harsh environments and systems in need of.
Please feel free to contact us if you need any further information or for enquiry.
