Hydraulic Sae Flange Ball Valve

Home > Hydraulic Sae Flange Ball Valve

Gabriel Tube Fittings is a top-notch manufacturer and supplier located in Cairo, Egypt, known for its high-quality Hydraulic SAE Flange Ball Valves. These valves are expertly crafted to ensure excellent flow control and secure connections in hydraulic systems that operate under high pressure. With a strong emphasis on precision engineering, durability, and leak-free performance, Gabriel Tube Fittings guarantees that each product meets international standards. The company caters to a variety of industries by providing reliable and efficient valve solutions that are specifically designed to handle demanding operational conditions in hydraulic and fluid transfer systems.

Hydraulic Sae Flange Ball Valve Supplier in Cairo, SAE Flanged End Ball Valve Price List in Alexandria, SS316 Ball Valves Manufacturer in Giza, Hexagon shape Hydraulic Sae Flange Ball Valve in Port Said, Hydraulic Sae Threaded Ball Valve Exporter in Alexandria, Hydraulic Sae Compression Ball Valve Manufacturer in Cairo, Hydraulic Sae Flange Ball Valve In Cairo, Egypt.

Typically, Hydraulic SAE Flange Ball Valves are made from carbon steel, stainless steel, or alloy steel, with options for nickel or zinc plating to boost corrosion resistance. They boast a sturdy body structure, a precision-machined ball, and PTFE or reinforced seals to ensure leak-proof performance. Mechanically, these valves are built to endure high pressure, operate smoothly, and offer excellent torque control. Their impressive tensile strength and fatigue resistance make them ideal for long-term use in tough industrial settings.

KhpHydraulic Sae Flange Ball Valve Specification

Size Range: 1/8″ TO 2″ / 6 MM TO 50 MM
Design: Quarter Turn Type
Material: Steel / SS316
Working Pressure: 3000 PSI / 6000 PSI
Connections: SAE Flanged End, Code 61 / Code 62
Brand: TU-LOK
Applicable Medium: General Hydraulic Oil (Gas Application on request)
Temperature Range for Steel Ball Valves: -20°C to +100°C
Temperature Range for SS316 Ball Valves: -30°C to +100°C
Ball Seats: POM (POM standard option, other materials on request)
Stem and Adaptor Sealing Materials: NBR (NBR standard option, other materials on request)

Top Hydraulic Sae Flange Ball Valve Manufacturing Company in Cairo

At Gabriel Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Sae Flange Ball Valve in Cairo, Egypt. Our advanced manufacturing facilities, strategically positioned in the Egypt, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands

types of ball valves

Valve Type	BKH / BKHP	MKH / MKHP	KH
Diameter Size	1/8″ to 1″	1 1/4” to 2	1/2” to 3”
Working Pressure	Up to 800 Bar	Up to 420 Bar	Up to 420 Bar
Body Design	Square shape	Round / Hexagon shape	Round shape
Connection Type	Threaded Compression Flange end	Threaded Compression Flange end	Flange end

Types of Hydraulic Sae Flange Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Hydraulic Sae Ball Valve Supplier In Giza, SAE Flanged End Ball Valve Exporter In Cairo, SS316 Ball Valves Dealer In Alexandria, Hydraulic Sae Hexagon shape Ball Valve Supplier in Cairo, Hydraulic Sae Threaded Ball Valve Price List in Alexandria, Hydraulic Sae Compression Ball Valve Manufacturer in Giza, Hydraulic Sae Flange end Ball Valve in Port Said, Hydraulic Sae Ball Valve Exporter in Alexandria, Hydraulic SAE Flanged End Ball Valve Manufacturer in Cairo, Hydraulic Sae Flange Ball Valve In Cairo, Egypt.

Ball valve with SAE flange flow rate

Nominal Diameter (mm)	Nominal Diameter (inch)	Kv (m3/h)	Cv (gal/min)
15	1/2″	19,4	22,6
20	3/4″	45,6	53,0
25	1″	71,5	83,1
32	1 1/4″	105	122,1
40	1 1/2″	170	197,7
50	2″	275	319,8
65	2 1/2″	507	589,5
80	3″	905	1052,3
100	4″	1414	1644,2
125	5″	2362	2746,5
150	6″	3694	4295,3

Hydraulic Sae Flange Ball Valve Supplier in Cairo, Egypt

Gabriel Tube Fittings is a leading supplier and Stockist of premium Hydraulic Sae Flange Ball Valve in Cairo, Egypt. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the fittings industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hydraulic Sae Flange Ball Valve Uses

You’ll find Hydraulic SAE Flange Ball Valves commonly used in hydraulic power units, mobile machinery, marine systems, and various industrial equipment. They are essential for managing fluid flow and ensuring reliable pressure control in heavy-duty operations. These valves are favored for their straightforward installation, compact design, and capability to handle high-pressure hydraulic circuits. Typical applications include construction machinery, agricultural equipment, offshore platforms, and industrial automation systems, where robust and leak-free flow control is a must.
